Foam Fire Extinguisher
Suitable for class a & b fires involving flammable liquid, petroleum products or where the blanketing effect is essential
Capacity (Ltrs.) | BIS Spec. | Discharge | Jet Length | Test Pressure |
9 Ltrs.. | 10204 | 60-80 | 6 | 30 |
Mechanical Foam (AFFF) |
We are suppliers Fire Extinguishers of Safex Fire Extinguisher, Minimax Fire Extinguisher, Lifeguard Fire Extinguisher,Unitex Fire Extinguisher, Lightex Fire Extinguisher, Omex Fire Extinguisher, Falcon Fire Extinguisher and other ISI, UL and FM Listed Fire Extinguisher.
Type: Water CO2 Type Fire Extinguisher, CO2 Fire Extinguisher
Specifications:
MODEL | Axis AFFF-09 |
Capacity (Ltr.) | 9 |
Anti-Corrosive Inhibitor | Epoxy Polyester Powder Coating |
Conforming IS Code | 15683 |
Type of Extinguisher | Constant Pressure/Gas Cartridge |
Type of Extinguisher Media | Water & AFFF IS 4989 |
Expellant | Pressurized with N2 gas/90gm/120gm Gas Cartridge |
Min. Effective Discharge (%) | 95 |
Min. Jet Length (mtrs.) | More than 2 mtr. |
Discharge Time (Sec.) | More than 13 sec. |
Hydraulic Test Pressure (kgf/cm2) | 35 |
Operating Position | Upright |
Charged Pressure(kgf/cm2) | 15 |
Operating Temperature Range(oC) | 0 to(+)55 |
Operating Valve | Squeeze Grip Type with Discharge hose and nozle |
Fire Rating | 3A, 55B |
