Home » Products » Fire Extinguishers » Clean Agent Fire Extinguisher

Clean Agent Fire Extinguisher

Clean Agent Fire Extinguisher
Clean Agent Fire Extinguisher
Product Code : CAE-01
Brand Name : AXIS FIRE PROTECTION
Product Description

Clean Agent Fire Extinguisher

The Clean Agent Fire Suppression System we offer is exclusively installed in industrial or commercialized sectors for advanced detection and subjugation of fire in electrical chambers. It is factory-made by our deft professionals utilizing quality oriented raw materials and precocious techniques at our sophisticated manufacturing unit. The Clean Agent Fire Suppression System we offer is FM approved. Fire detect sections are FM sanctioned when put in in a decently configured system in compliance with NFPA 2001 regulation.

Features:

  • Easy installation, superior sensitivity
  • Immune to spurious operations, speedy and hard-hitting suppression.
  • Easy, adjustable installment, highly economical
  • Highly reliable: No electricity or tossing parts

Specifications:

FIRE EXTINGUISHER CAPACITY

1kg.

2kg.

4kg.

6kg.

MINIMUM PERIOD FOR WHICH THROW OF JET MAINTAINED

8 Sec

8 Sec

16 Sec

20 Sec

MINIMUM PERIOD OF DISCHARGE ATLEAST 90% OF CONTENTS

10 Sec

16 Sec

20 Sec

25 Sec

RANGE OF JET

1mtr.

1mtr.

2mtr.

2mtr.

EMPTY WT. (APPROX)

1.2kg.

2.3kg.

2.75kg.

3.3kg.

FULL WT. (APPROX)

2.0kg.

4.3kg.

6.75kg.

9.3kg.

FIRE RATING

8B

8B

1A, 34B

21B

WORKING PRESSURE

15 KGF/CM2

15 KGF/CM2

15 KGF/CM2

15 KGF/CM2

HYDRO PRESSURE

35 KGF/CM2

35 KGF/CM2

35 KGF/CM2

35 KGF/CM2

BRUSTING PRESSURE

55 KGF/CM2

55 KGF/CM2

55 KGF/CM2

55 KGF/CM2

EN3.7

IS :15683

Performance Data:

Size

Propellant

Working Pressure

Testing Pressure

Area Protection

Volume Protected

Hanging Vertically Above Risk

Operation Time in Second

02 Kg

Clean Agent

7 to 15 Kgs/cm2

35 Kgs/cm2

1 to 1.5 m2

3m2

1.5m

8-10

05 Kg

Clean Agent

7 to 15 Kgs/cm2

35 Kgs/cm2

3.5 to 4 m2

8m2

1.5m to 2m

10-15

10 Kg

Clean Agent

7 to 15 Kgs/cm2

35 Kgs/cm2

7 to 8 m2

15m2

1.75m to 2.25m

15-20

15 Kg

Clean Agent

7 to 15 Kgs/cm2

35 Kgs/cm2

8 to 10 m2

20m2

2m to 3m

18-23
